Products

  • 7.3M HVLS large ceiling fan for garage

    7.3M HVLS large ceiling fan for garage

    7.3M HVLS large ceiling fan for garage

    KQ series of large fans to generate natural breeze blowing on the human body, promote the evaporation of sweat to take away heat, and make the human body cool, bring cooling feeling.

    Usually, the body feeling temperature can be decrease by 5-8 ℃. The three-dimensional natural wind blowing of large fans is more comfortable because:
    On the one hand, the omni-directional three-dimensional blowing of the human body makes the evaporation area of the human body reach the maximum;
    On the other hand, human beings have accumulated a kind experience of natural wind in nature. Once there is a natural breeze blowing with the change of wind speed, the human body will naturally feel extremely comfortable and cool.

    SPECIFICATION

    Model

    Size

    (M/FT

    Motor

    (KW/HP

    Speed

    (RPM)

    AirVolume

    (CFM

    Current

    (380V

    Coverage

    (Sqm)

    Weight

    (KGS)

    Noise

    (dBA)

    OM-KQ-7E

    7.3/2.4

    1.5/2.0

    53

    476,750

    3.23

    1800

    128

    51

    OM-KQ-6E

     6.1/2.0

     1.5/2.0

     53

     406,120

     3.56

     1380

     125

    52

    OM-KQ-5E

    5.5/18

     1.5/2.0

    64

    335,490

    3.62

    1050

    116

    53

    OM-KQ-4E

    4.9/16

     1.5/2.0

    64

    278,990

    3.79

    850

    111

    53

    OM-KQ-3E

    3.7/12

     1.5/2.0

    75

    215,420

    3.91

    630

    102

    55

    *Fan sound are teated in expert lab by running on maximum speed,and noise may vary due to  different environments and surroundings.

    *Weight excluded mounting bracket and extension tube.

    PRODUCT WARRANTY

    Product warranty period: 36 months for complete machine after delivery.For failures within the warranty period, please do not try to solve by yourself, the company can send you a free onsite professional service.

    PROJECT CASES

    98a8cedc40f15335348fdd3f1a60d5e6a894020b7f3993ff2d3940ed237692d7c34fd1d3b13b296bd8a9a4778f693f79190fb4e559ac1b220230d9d1d94f

    Food courts                         Exhibition Halls

    Shopping Malls                  Schools

    Discotheques                     Places of Worships

    Sports Halls                       Warehouses/ Workshops

    Multipurpose Halls          Manufacturing Facilities

    Athletic Stadiums            Airports

    Community Centers        Military Facilities

    FAQ

    Q1: What is the MOQ?

    No any requirements, 1 pcs can be accepted.

    Q2: Compare with the pictures,I prefer to see the real products,Can you promise your products are the same with the pictures?

    All the pictures were taken from real products,so the quality can be guaranteed,You can place sample order first .

    Q3: Some of my orders are urgent, I don’t want to wait long time, can you guarantee mass production period .

    We suggest you contact our sales for urgent orders ,usually 3-5days for stock items,7-15day for mass production period .

    Q4: Can all products be customized?

    Yes,all of products can be customized according to customers’ requirements.

    Q5: What’s the delivery time?

    5-7days if the order is less than 30sets.

    Q6: What’s the warranty time of your HVLS fan?

    We provide the quality certification, user manual, packing list, quality feedback card.
    All the components is 3 years warranty,fans hub and blades is lifetime warranty.

    Q7: Is OEM&ODM service available for you?

    Yes.We have professional R&D team to satisfy your OEM&ODM requirements.

  • 2M DC Gym Floor Fans

    2M DC Gym Floor Fans

    Airwalker II Series  is  a new generation of HVLS Mobie Floor with PMSM motor,fan diameter is 2m, which can provide ultra-long air blowing, the effective distance is more than 20m.

  • 2M PMSM Mobile Warehouse Fans

    2M PMSM Mobile Warehouse Fans

    Airwalker II Series  is  a new generation of HVLS Mobie Floor with PMSM motor,fan diameter is 2m, which can provide ultra-long air blowing, the effective distance is more than 20m.

  • 14 ft HVLS PMSM Commercial DC Fans

    14 ft HVLS PMSM Commercial DC Fans

    1.Large coverage area of the breeze air blowing can be 133900CFM .

    2.Ideal for usage in big open space the height is over 3.5 meters.

    3.Silent and energy efficient large industrial ceiling fan,Reduced heating energy consumption by up to 30% on lowest setting



  • 12 ft HVLS Ceiling Fan PMSM Commercial Fans For Public 109,200CFM

    12 ft HVLS Ceiling Fan PMSM Commercial Fans For Public 109,200CFM

    1.Large coverage area of the breeze air blowing can be 84,600CMM .

    2.Ideal for usage in big open space the height is over 5 meters.

    3.Silent and energy efficient large industrial ceiling fan.

  • 14 ft HVLS Ceiling Fan 133,900CFM PMSM Commercial Large Cooling Fans

    14 ft HVLS Ceiling Fan 133,900CFM PMSM Commercial Large Cooling Fans

    1.Large coverage area of the breeze air blowing can be 133900CFM .

    2.Ideal for usage in big open space the height is over 3.5 meters.

    3.Silent and energy efficient large industrial ceiling fan,Reduced heating energy consumption by up to 30% on lowest setting



  • OPT 10FT HVLS PMSM Motor Industrial Cooling Ventilation Fans

    OPT 10FT HVLS PMSM Motor Industrial Cooling Ventilation Fans

    1.Large coverage area of the breeze air blowing can be 84,600CMM .

    2.Ideal for usage in big open space the height is over 5 meters.

    3.Silent and energy efficient large industrial ceiling fan.

    4.Patented airfoil system maximizes performance and efficiency with six airfoils

    5.Fully adjustable airflow with variable speed controller

    6.Reduced heating energy consumption by up to 30% on lowest setting

    7.Fan is controllable by a wall controller.

    8.With PMSM(permanent magnet synchronous motor),the performance of fan is further improved.

  • 10 Ft HVLS Ceiling Fan – PMSM Motor-For Industrial/Commercial

    10 Ft HVLS Ceiling Fan – PMSM Motor-For Industrial/Commercial

    OPT 10FT HVLS PMSM Motor Industrial Cooling Ventilation fans With whisper-quiet brushless motors that would make a dormouse seem loud, and sleek, award-winning designs that will transform your ceiling into a centerpiece, our commercial fans will make everywhere from offices to breweries to……

  • 4.2M HVLS PMSM DC Home Ceiling Fans

    4.2M HVLS PMSM DC Home Ceiling Fans

    OPT Navigator Series use PMSM(Permanent Magnet Synchronous Motor) for low noise, high performance, and free maintenance . PMSM used for superior and high-efficiency motor drives.

  • 18FT HVLS KQ Big Industrial Heater Ventilation Fans

    18FT HVLS KQ Big Industrial Heater Ventilation Fans

    OPT HVLS fans not only can be used in summer for cooling and ventilation,but also spread warm air exploding from heater .Slow-moving air column carries warm air from the ceiling down to floor level….

  • 20FT HVLS Giant Ventilation Fans

    20FT HVLS Giant Ventilation Fans

    OPT HVLS Ceiling Industrial Ventilation Fan safety device: each fan blade is equipped with L-type safety link buckle to prevent the blade from separate sections, and the mold shaft sleeve is designed to prevent the rotating chassis from slipping accidentally. All fasteners are equipped with anti loose self-locking nuts and tooth shaped drop pads….

  • 24 FT Best Outdoor Ceiling Fans

    24 FT Best Outdoor Ceiling Fans



    Warehouses and logistics facilities generally surround a large square image that is full of machin



    ery, people, and even light fixtures that give off heat. These areas may be affected by climate



    zones, poor air quality, and inconvenient temperatures, which may reduce energy inefficiency and



    safety concerns of managers.



12345 Next > >> Page 1 / 5
